Air Recycling range

Sunkiss VRX20-30 and VR 10000 Thermoractors®

The high power density of the infrared radiant of the Air Recycling range offers high energy efficiency. It is intended for firing large volume aluminum and metal parts. It also has an air recirculation option, which captures hot air from the oven to add convection and improve cooking. Its drying or baking temperature ranges between 158° F (70° C) and 572° F (300° C)

Other advantages of the Thermoreactor® from the Air Boost range:

  • Agreement of infrared emission spectra and absorption of organic coatings.
  • Contribution of convectional energy, complementary to radiant energy.
  • Recycling of the ambient air of the tunnel increasing the cooking efficiency
  • Regulation by the variation of the gas pressure.
  • Time saving with a drying time reduced up to 4 times.
  • Space saving thanks to a more compact and shorter tunnel.
  • Increased quality resulting in a better finished appearance and better tension of the paint film.
  • Energy savings with a reduction in consumption of more than 50%.
  • Energetic efficiency
  • Productivity improvement
  • Floor space optimization
  • Finish quality

Product role

Some examples of industrial applications of the SUNKISS Thermoreactor® from the Air Recycling range for drying ovens:

  • Wagons
  • Agricultural machinery
  • Construction machinery
  • Containers

The Air Recycling range is suitable for all large volume parts.
VRX infrared Thermoreactor®

VRX 20 Model

  • Power:  22kW
  • Weight: 58 kg
  • Dimensions: 1200 x 660 x 370 mm
  • Radiant surface: 940 x 470 mm

VRX 30 Model
  • Power: 33 kW
  • Weight: 68 kg
  • Dimensions: 1600 x 660 x 370 mm
  • Radiant surface: 1410 x 470 mm

Connection box:
  • Gas supply by main solenoid valve and starter
  • Connection terminal block for a digital temperature controller
VR 10000 infrared Thermoreactor®
  • Power: 14.4 KW
  • Weight: 30 kg
  • Dimensions: 1550 x 350 x 290 mm
  • Configured for air recirculation
  • Wall fixing: by support
  • Radiant surface: 1220 x 265 mm
  • Connection box :
    • Gas supply by main solenoid valve and starter
    • Connection terminal block for a digital temperature controller

Our Thermoreactors ®
Industrial infrared radiators, 3 ranges to properly target needs
proven technology
since 1953

Our products are used in different fields

Benefiting from unique expertise in painting systems and its experience in several industrial sectors, Sunkiss-EPI designs and manufactures equipment for various applications, including:
  • Aeronautical
  • Construction materials
  • Metal products manufacturing
  • Wood finishing
  • Painting subcontractor
  • Doors and windows
  • Agricultural machinery
  • Recreational facilities
  • Transports
  • Lighting
  • Aluminium extrusion
  • Architectural materials
Do not hesitate to contact us for more information or to obtain an evaluation of your system.
